The MicroZed Chronicles - Using the Zynq 101 - Complete Second Year

Adam Taylor 2016

The complete year two of the MicroZed Chronicles, this book starts off with the linux operating system on the Zynq. Progresses on to constraints, using PicoBlaze with the Zynq. Ethernet Communications and a in depth SPI example. The second half of the book is focused upon the SDSoC tool and it completes with a in depth AES example.


Make: FPGAs: Turning Software into Hardware with Eight Fun and Easy DIY Projects

David Romano 2016

What if you could use software to design hardware? Not just any hardware--imagine specifying the behavior of a complex parallel computer, sending it to a chip, and having it run on that chip--all without any manufacturing? With Field-Programmable Gate Arrays (FPGAs), you can design such a machine with your mouse and keyboard. When you deploy it to the FPGA, it immediately takes on the behavior that you defined. Want to create something that behaves like a display driver integrated circuit?...


The MicroZed Chronicles - Using the Zynq 101: Complete First Year

Mr Adam P Taylor CEng 2015

The Xilinx Zynq System on Chip is the SoC in demand at the moment, the MicroZed Chronicles takes you in 52 lessons from the beginning of hello world to creating peripherals within the FPGA and adding in operating systems to make you be able to use the device like a seasoned professional. With over 150 images used to illustrate the lessons and numerous code examples key areas include The Zynq & the SW development environment Configuring the device and generating a boot image XADC &...


Design Recipes for FPGAs, Second Edition: Using Verilog and VHDL

Peter Wilson 2015

This book provides a rich toolbox of design techniques and templates to solve practical, every-day problems using FPGAs. Using a modular structure, it provides design techniques and templates at all levels, together with functional code, which you can easily match and apply to your application. Written in an informal and easy to grasp style, this invaluable resource goes beyond the principles of FPGAs and hardware description languages to demonstrate how specific designs can be synthesized,...


Logic Design and Verification Using SystemVerilog

Donald Thomas 2014

SystemVerilog is a Hardware Description Language that enables designers to work at the higher levels of logic design abstractions that match the increased complexity of current day integrated circuit and field-programmable gate array (FPGA) designs. The majority of the book assumes a basic background in logic design and software programming concepts. It is directed at: • students currently in an introductory logic design course that also teaches SystemVerilog, • designers who want to...


Vhdl By Example

Blaine Readler 2014

A practical primer for the student and practicing engineer already familiar with the basics of digital design, the reference develops a working grasp of the Vhld hardware description language step-by-step using easy-to-understand examples. Starting with a simple but workable design sample, increasingly more complex fundamentals of the language are introduced until all core features of Vhdl are brought to light. Included in the coverage are state machines, modular design, Fpga-based memories,...


Advanced Chip Design, Practical Examples in Verilog

Mr Kishore K Mishra 2013

Designing a complex ASIC/SoC is similar to learning a language well and then creating a masterpiece using experience, imagination, and creativity. Digital design starts with RTL such as Verilog or VHDL, but it is only the beginning. A complete designer needs to have a good understanding of the Verilog language, digital design techniques, system architecture, IO protocols, and hardware-software interaction that I call the five rings of chip design. This book is the result of 20 years of...


Verilog by Example: A Concise Introduction for FPGA Design

Blaine Readler 2011

A practical primer for the student and practicing engineer already familiar with the basics of digital design, the reference develops a working grasp of the verilog hardware description language step-by-step using easy-to-understand examples. Starting with a simple but workable design sample, increasingly more complex fundamentals of the language are introduced until all major features of verilog are brought to light. Included in the coverage are state machines, modular design, FPGA-based...


100 Power Tips For FPGA Designers

Evgeni Stavinov 2011

This book is a collection of short articles on various aspects of FPGA design: synthesis, simulation, porting ASIC designs, floorplanning and timing closure, design methodologies, performance, area and power optimizations, RTL coding, IP core selection, and many others. The book is intended for system architects, design engineers, and students who want to improve their FPGA design skills. Both novice and seasoned logic and hardware engineers can find bits of useful information. This book is...


Digital Design with RTL Design, VHDL, and Verilog

Frank Vahid 2010

An eagerly anticipated, up-to-date guide to essential digitaldesign fundamentals

Offering a modern, updated approach to digital design, thismuch-needed book reviews basic design fundamentals before divinginto specific details of design optimization. You begin with anexamination of the low-levels of design, noting a clear distinctionbetween design and gate-level minimization. The author thenprogresses to the key uses of digital design today, and how it isused to build high-performance...
